EV 12" TWO-WAY POWERED LOUDSPEAKER - 375 WATT

ELEEKX-12P

New product

12" Two-Way Powered Loudspeaker - 375 Watt

More details

EKX-12P features high-efficiency Class-D power amplifiers (up to 1500 W) with integrated QuickSmartDSP, and delivers up to 132 dB SPL utilizing high-sensitivity transducers designed and engineered by EV (12-inch EVS-12M woofer coupled with a DH-1M 1-inch titanium compression driver).

The EKX amplifier incorporates intelligent thermal management (with a variable-speed fan controlled by multiple onboard sensors) which ensures superior performance and reliability in demanding environmental conditions.

Powered full-range models allow easy setup via four (4) presets (Music, Live, Speech, Club), sub/top system-match crossovers, three-band EQ, five (5) user-programmable presets (Store and Recall settings), visual monitoring of limiter status, input level control and meters, and master volume control to ensure optimal gain structure.

EKX powered models are ideal for portable and installed applications, with lightweight and compact 15-mm wood enclosures with internal bracing, durable EVCoat finish, eight (8) M10 threaded mounting points, aluminum pole-mounts, and all-metal handles.

Features

• QuickSmartDSP features best-in-class processing, EV’s signature single-knob user interface, and intuitive menu navigation via LCD.

• High-efficiency 1500 W Class-D power amplifier delivers up to 132 dB SPL via high-sensitivity transducers designed and engineered by EV.

• Intelligent thermal management with a variable-speed fan controlled by multiple onboard sensors.

• EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage.

• Lightweight, compact 15-mm wood enclosure with internal bracing, durable EVCoat finish, eight (8) M10 threaded mounting points, aluminum pole-mounts, and all-metal handles.

  • Colour Black
  • Coverage (H x V) 90° x 60°
  • Dimensions (H x W x D) 607 x 375 x 356 mm
  • Frequency Response 50 Hz - 20 kHz (-10 dB):
  • Material 15 mm plywood with EVCoat
  • Maximum SPL 132 dB
  • Power Rating 1500 Watt
  • Suspension Points 8 x M10 threaded mounting points
  • Warranty 3 Years
  • Weight 18.8 kg
