> >>AUDIOROPA 2 CHANNEL INFRARED MID-RANGETRANSMITTER/MODULATOR
2 Channel Infrared Mid-RangeTransmitter/Modulator View larger

HUMANTECHNIK

AUDIOROPA 2 CHANNEL INFRARED MID-RANGETRANSMITTER/MODULATOR

MADHT-A-4082-0

HT-A-4082-0

New product

2 Channel Infrared Mid-RangeTransmitter/Modulator

More details

Balcatta: 0
Geebung: 0

Simply couple the PRO IR-200 with any of Humantechnik's range of Infrared receivers and you have a complete assistive listening system configured and operating in minutes.

Many situations will make traditional induction loops an impractical, costly or time consuming solution. This is where an infrared system becomes a more logical choice. Infrared systems are simple to setup and are flexible by design. This makes them particularly useful for temporary spaces, education facilities, and virtually any environment where induction loop systems cannot be installed.

The transmission energy of PRO IR-202 Transmission/Modulator unit (Master) spreads club-shaped in the room in a broad aperture angle (see illustration bottom right). The audio transmission is interference-free due to the infrared signal modulation in 2.3 and/or 2.8 MHz. The combination of the PRO IR-202 with another  PRO-IR-202 transmitter, set up as a slave, increases the range and the dispersion angle of the infrared signals up to 240°.

A set for ceiling and wall mounting is included in the delivery. A stand A-4986-0 is available as an accessory.

Combining two PRO IR-202 is achieved with the included installation kit. The units mounted on top of each other can be freely turned to the required angles to achieve optimal signal supply in the room. The range of the Master with 2 Slave units is up to 560 m² at one channel transmission - ideal for large rooms.

With the selection of the suitable receiver type (RCI-102, PR-22+ or IP112) the range can be further influenced, depending on the sensitivity of the receiver diodes.

Features

  • Broad exit angle of infrared signals
  • Configuration with 1 and 2 channel transmission
  • Modularity: Up to two PRO IR-202 transmitters can be combined into a Master/Slave unit
  • Power supply of Slave unit via connection cable
  • Operation of Master-Slave configuration with a single power supply unit
  • Usable as fixed (wall or ceiling mount) or mobile installation (e.g. stand)
  • Colour Black
  • Dimensions (H x W x D) 64 x 254 x 79mm
  • Warranty 2 Years
  • Weight 300 g
